SplinergySW D1P-4G Single-Phase DIN-Rail Smart Meter (4G)
SplinergySWD1P-4G

Single-Phase DIN-Rail Smart Meter (4G)

The D1P-4G drops into any consumer unit on a standard 35 mm DIN rail and reports straight to the Splinergy cloud over 4G LTE. Ideal where there is no reliable Wi-Fi: each unit is independently online, so a single tenant, room or circuit can be metered, billed and switched remotely.

  • 1-phase
  • DIN rail
  • 4G LTE
  • Remote on/off
RM200.00/ unit
+ RM 10 per meter per month for the Splinergy platform · Pricing
SKU EMS-MTR-SW-D1P-4G
Get a quote on WhatsApp All products

What it does

01

Remote power on / off

Built-in relay lets you cut or restore supply from the Splinergy platform, manually or automatically when a prepaid balance runs out.

02

Prepaid & postpaid billing

Tenant balance, top-ups and usage charges are tracked per meter and reconciled automatically.

03

Live readings

Voltage, current and cumulative kWh pushed to the cloud for real-time monitoring.

04

Consumption analytics

Daily, 7-day and monthly usage history per meter, ready for invoicing and audits.

Specifications

Phase / wiringSingle-phase, 2-wire
Rated voltage220 V AC, 50 Hz
Max current60 A (direct connection)
Mounting35 mm DIN rail
Communication4G LTE (built-in)
DisplayLCD, kWh
Load controlBuilt-in relay, remote on/off
IndicatorsPulse · Trip · Network

Use cases

Hostel & co-living rooms
Shoplots & retail units
Factory sub-circuits
Sites without Wi-Fi

Runs on the Splinergy platform

Live dashboards, automated tenant billing with DuitNow, FPX, cards and e-wallets, prepaid cut-off and remote control, all from one web and mobile platform.
